Fractal Design Define 7 Mini (Black TG) Gaming Case w/ Light Tint Glass Window, Micro ATX, Sound Dampening, Ventilated PSU Shroud, USB-C, 331mm GPU & 240mm Radiator Support

Re-defining sleek.


The Define 7 Mini offers many features from its larger siblings in a smaller form factor. The compact yet spacious interior accommodates mATX and Mini ITX motherboards, and there's room for a GPU up to 331 mm with a 240 mm radiator in the top (or a GPU up to 306 mm with 25 mm front fans).


Compact yet spacious interior accommodates mATX and Mini ITX motherboards
Room for GPUs up to 331 mm with a 240 mm radiator in the top, or 306 mm with 25 mm thick fans in the fronts
Support for 2x 2.5”/3.5” drives and up to 4x 2.5” drives (2x 2.5” brackets included)
Top panel effortlessly swaps from solid steel to filtered ventilation
New removable top panel design opens up to fully expose the case interior for effortless installation and cable routing
Silence-optimized construction with industrial sound-damped front, top, and side panels
Brushed aluminum front and top-latching side panels offer a clean sophisticated look
Install up to 7x 120 mm or 4x 140 mm fans (1x 120 mm and 1x 140 mm Dynamic X2 fans included)
Five front USB ports including one USB 3.1 Gen 2 Type-C with fast-charging support and speeds up to 10Gbps
Bridgeless expansion slots ensure obstruction-free connections for easier installation and hookup
Ventilated PSU shroud with two-part removable cover for optimal coverage and front radiator support
Easy-to-clean high airflow nylon filters on the front, top and base with full PSU coverage and convenient front access
Integrated cable guides with velcro straps further simplify cable management behind the board


-Form Factor
Micro ATX
-#Hide#Small Form Factor
No
-Power Supply Wattage
No PSU
-Motherboard Support
Micro ATX, Mini ITX, Mini DTX
-#Hide#Window(s)
Yes (Window)
-Connectors / Controls
1 x USB 3.1 Gen 2 Type-C
2 x USB 3.0
2 x USB 2.0
Audio
-Drive Bays
3.5"/2.5" drive mounts: 2 (included)
Dedicated 2.5" drive mounts: 4 (2 included – note the 8 mm height limit on two of the positions)
-Expansion Slots
4 Expansion slots
-Cooling System
<strong>Included</strong>
Front: 1 x Dynamic X2 GP-14 140mm fan
Rear: 1 x Dynamic X2 GP-12 120mm fan

<strong>Fan Mounts</strong>
Front: 3 x 120 / 2 x 140 mm
Top: 2 x 120 / 2 x 140 mm
Rear: 1 x 120 mm
Bottom: 1 x 120 mm (requires removal of HDD cage)
-.

<strong>Radiaitor options:</strong>
Front: Up to 280 mm (361 mm max height, 146 mm max width)
Top: 120/240 mm (max 37 mm RAM with 121 mm wide radiator)
Rear: 120 mm
Bottom: 120 mm (requires removal of HDD cage)
-Colour
Black
-Material
Left side panel: Tempered glass
Right side panel: Industrial sound-damped steel
-Compatability
<strong>GFX Card length:</strong>
331 mm
306 mm with front fan

<strong>Max CPU Cooler:</strong>
167 mm

<strong>Max PSU length:</strong>
165 mm recommended with HDD cage
200 mm without HDD cage
-Weight/Dimensions
6.84 kg
(LxWxH) 399 x 205 x 406 mm
-Additional Features
See Overview
-Accessories
User manual
Accessory box
Ventilated top panel
-Package Weight
9.4000 kg
-Warranty
2 Years

Manufacturer
FRACTAL
More products by FRACTAL

Product Reference
7340172702825
