Antec DP505 Gaming Case w/ Glass Window, E-ATX, X-Shaped Mesh Front, 3 ARGB Fans, RGB/PWM Controller, LED Control Button, USB-C, White

Icy Cooling Performance Gaming Case

High-Airflow Mesh Front Panel
Built-in ARGB/PWM controller supporting up to 6 fans
Case supports up to 9 fans simultaneously
Supports E-ATX, ATX, Micro-ATX, and ITX motherboards
Top and Bottom Dust Filters

High Airflow Mesh Front Panel Design
The DP505 White gaming case features a massive X-shaped mesh front panel and ventilation on top, at the bottom, and in the PSU chamber, which will accelerate the airflow circulation and enhance the cooling performance

Maximum Expansion Potential
The DP505 White gaming case features an extensive interior and powerful compatibility. 2 x 360mm can be installed in the front & on the top simultaneously.
High-Airflow Mesh Front Panel with X-Shaped Design
Features a massive X-shaped mesh front panel and ventilation on the top, at the bottom, and in the PSU chamber, which will accelerate the airflow circulation and enhance the cooling performance.
Massive Mesh Front Panel with X-Shaped Design.
The Magnetic Dust Filter on the Top.
Pull-Out Dust Filter at the Bottom.
Three addressable RGB fans Included
Pre-installed at the front for efficient airflow and customizable RGB lighting.
ARGB & PWM control Hub
The control hub supports up to 6 fans and 6 LED device.
Connect it to your motherboard for 16.8 million possible colors.
Building a clean PC is within easy reach
Well-designed cable routing makes wiring easy and simple, with a spacious 23mm of space for cables.
Easy installation
Fits Up To 4 Drive Devices
Snap-in 2.5" drive device for easy mounting.
Removable hard drive cage.
Tool-free 3.5" drive tray
9 fans simultaneously
3 x 120mm ARGB fans and a 360 mm radiator can be installed simultaneously in the front interior for better cooling performance.


-Form Factor
E-ATX
-#Hide#Small Form Factor
No
-Power Supply Wattage
No PSU
-Motherboard Support
E-ATX, ATX, Micro ATX, Mini ITX
-#Hide#Window(s)
Yes (Window)
-#Hide#LED Lighting
Yes (LED Lighting)
-Connectors / Controls
1 x USB Type-C 3.2 Gen2
2 x USB 3.0
1 x Mic
1 x HD Audio x 1
Power button
LED control button
-Drive Bays
2 x 3.5"/2.5"
2 x 2.5"
-Expansion Slots
7 Expansion slots
-Cooling System
<strong>Included:</strong>
Front: 3 x 120mm ARGB fans

<strong>Fan Support</strong>
Front: 3 x 120 / 3 x 140 / 2 x 185 mm
Top: 3 x 120 / 2 x 140 mm
PSU Shroud: 2 x 120 mm
Rear: 1 x 120 mm
-.

<strong>Water Cooling options:</strong>
Front: Up to 360 mm radiator
Top: Up to 360 mm radiator
Rear: 120 mm radiator
-Colour
White
-Material
Steel + Plastic
Tempered Glass side panel
-Compatability
<strong> GFX Card:</strong>
375 mm

<strong> Max CPU Cooler:</strong>
170 mm

<strong> PSU:</strong>
205 mm (with HDD)
410 mm(without HDD)
-Weight/Dimensions
7.88 kg
(DxWxH) 481 x 220 x 490 mm
-Additional Features
See Overview
-Package Weight
9.1000 kg
-Warranty
2 Years

Manufacturer
ANTEC
More products by ANTEC

Product Reference
0761345810760
